ADC PCIe 5 GS/s collection card(XCIe-50)

Date of issue: 2019-01-22
Source:
Browse: 27
Share to:

ADC PCIe 5GS/s 采集卡(XCIe-50)



ADC parameters

1) 1.25 GS/s, 2.5 GS/s, 5 GS/s sampling rate can be set:

2) When only one channel is used, it is 5GS/s;

3) When CH1 and CH2 are selected for use, and CH3 and CH4 are selected for use, it is 2.5 GS/s;

4) When CH1 and CH2 are used at the same time, or CH3 and CH4 are used at the same time, the four channels are all 1.25 GS/s;

5) Sample number: 10 bit;

Board Memory

2GB capacity DDR-3, 64-bit wide;

External trigger signal input port

1) 1 trigger signal input port;

2) 5VTTL level;

3) No damage within 0 ~ 5.5 V;

4) The maximum repeat frequency can be supported to 1MHz.
